Aqualine Drainage Trough


An innovative alternative to traditional concrete drainage channel/trough, Aqualine is manufactured from approx. 7 mm thick chopped strand Glass Fibre and a polymer resin, which is manufactured by one of the worlds leading suppliers and has been sufficiently tested to achieve Lloyd’s Register Shipping Approval for all marine and boat applications and WRAS (Water Regulations Advisory Scheme) Approval (suitable for use with potable water) and is used extensively in water tank construction and water treatment applications.

Additionally, Aqualine is…

  1. Available in various sizes to suit site specific requirements.
  2. Available as a perforated channel to allow inflow from the surrounding ground.
  3. Quick and easy to install.
  4. Supplied complete with 38 x 38 mm (30 x 30 mm Clear Opening) blue grated covers, 25 mm thick.
  5. Supplied complete with 8 mm Ø Stainless Steel spacer bars to prevent any deflection of the channel preventing lid removal/ replacement.
  6. Available with flexible bend s ections for ease of installation.
  7. Fire Resistant, tested in accordance with NR/L2/TEL/00013/04 and BS EN ISO 11925-2:2020.
  8. Load tested in accordance with BS EN 124 and subsequently A15 rated.

Fire Testing Summary

Multiple fire tests were conducted on the Aqualine trough at the premises of Aqua Fabrications to ascertain the degree of resistance of the product. There were three tests completed on the trough and four on the lid. The tests consisted of a flash fire, a slow burn low heat/flame and a high heat high flame intense burn. These were completed on both sections of the product. The fourth test consisted of a sustained intense fire to the underside of the lid...
